Free Shipping. Delivery time in about 2 weeks due this bike being built-to-order.
The Juggernaut Classic Duo Step-Thru is back by popular demand. This time round, there are many improvements such as an integrated battery and motor, suspension fork and much more.
Our Juggernaut was the first electric fat bike that has a custom Bafang BBS02B motor built into the frame - more ground clearance than any other BBS powered bikes.
Both the Juggernaut Classic variants come with throttle-on-demand and Cadence/PAS (Pedal Assist Sensor). As you pedal, the motor measures how often you're pedaling and helps you proportionally.
You can boost motor performance by setting assist levels between 1 to 5 levels where level 1 gives you least assist but most range while level 5 gives you maximum assist and least range.
The mid-motor makes this e-bike versatile. The Juggernaut Classic Duo features optional dual batteries that allow you to go as far as you desire - and never worry about range.
~Why buy Juggernaut Classic Duo Step-Thru~
✔️ 750W Bafang BBS02 Mid-drive Motor
✔️ 120Nm of torque for easy to moderate hills
✔️ 265lb load capacity
✔️ On-Demand throttle makes pedaling optional
✔️ Cadence sensor makes pedal-assist smooth and powerful
✔️ Includes 52V 17Ah 910Wh internal battery + charger
Features:
Suspension Fork
The RST Guide fork provides 80mm of travel with pre-load, lockout, and rebound adjustability
Hydraulic Disc Brakes
When it's so easy to go fast, you need strong stopping power. These hydraulic disc brakes will quickly and reliably bring you to a halt.
Optional Range-Extender
Multiple range-extender battery options can expand your eBike's range all the way to 100 miles.
Mid Drive Motor
The Bafang BBS02 mid-drive motor features 750 watts power and 120Nm of torque. This allows you to span cities, climb hills, and explore all the places you want to go with ease.
Integrated Front Light
This bright LED light is powered by the bike's battery and can be turned on/off with a button on the handlebar control pad
Thumb Throttle and Control Pad
With just a push of the thumb, you can access all of the power the motor has to offer. No need to pedal, just sit back and enjoy the ride.
Rack and Fenders
These fenders will keep you and your bike clean. Need to carry some gear? Strap on the rear rack and make your way!
Drivetrain
From climbing hills to holding maximum speed on the flats, the Shimano 9-speed drivetrain has you covered.
LCD Display
The LCD display shows all kinds of important information about your ride including speed, battery life, range, odometer, pedal assist level and more
Specifications:
- FRAME: 6061 Aluminum
- BRAKES: Tektro E350 Dual Piston w/ 180mm Rotors
- BATTERY SIZES: Total Capacity of 52V 36.5Ah 1898Wh:
52V 17.5Ah 910Wh (Internal Battery) +
up to 52V 19Ah 988Wh (External Range Extender Battery)
- FORK: RST Guide w/80mm Travel, Lockout and Preload
- BRAKE LEVERS: Tektro Adjustable w/ Integrated Brake Cutoffs
- HEADSET: Threadless 1-1/8 1-1/2 Tapered
- HANDLEBAR: 31.8mm Clamp, 700mm Wide, 80mm Rise
- SHIFTER REAR: Shimano 9 Speed Trigger
- STEM: 90mm Adjustable
- REAR DERAILLEUR: Shimano 9 Speed
- GRIPS: Comfort Grips
- CASSETTE: 12-36T
- SEAT POST: 27.2mm
- CHAIN: KMC 9 Speed
- SEAT POST CLAMP: QR
- CRANK SET: 44T 170mm Arms Chainring
- SADDLE: Wide Saddle
- BOTTOM BRACKET: Bafang Square Taper
- MOTOR: 750W Bafang BBS02 Mid-Drive
- FRONT HUB: 135mm 36H
- DISPLAY: DPC-18
- FRONT AXLE/SKEWER: 15mm QR
- LIGHTS: Integrated Headlight, Taillight
- REAR HUB: 170mm 36H
- THROTTLE: Thumb Throttle
- REAR AXLE/SKEWER: 5mm QR
- ASSIST LEVELS: 1-5
- RIMS: 26x4, 27.5x3, 24x4
- ASSIST TYPE: Cadence
- TIRES: 24x4", 26x4", 27.5x3"
- OTHER: Front and Rear Metal Fenders, Rear Rack, Kickstand
Size & Fitting:
17" STEP-THRU |
19" STEP-THRU |
||||
1 | Effective Top Tube Length | 640 mm | 25.2 inches | 640 mm | 25.2 inches |
2 | Seat Tube Length (Classic Bike Size) | 420 mm | 16.5 inches | 470 mm | 18.5 inches |
3 | Reach | 460 mm | 18.1 inches | 510 mm | 20.1 inches |
4 | Stack | 660 mm | 26 inches | 600 mm | 23.6 inches |
5 | Chainstay Length | 520 mm | 20.5 inches | 520 mm | 20.5 inches |
6 | Standover Height | 400 mm | 15.7 inches | 420 mm | 16.5 inches |
7 | Head Angle | 68 ° | - | 68 ° | - |
8 | Seat Angle | 71 ° | - | 71 ° | - |
9 | Head Tube Length | 140 mm | 5.5 inches | 140 mm | 5.5 inches |
10 | Fork Length | 530 mm | 20.9 inches | 530 mm | 20.9 inches |
11 | Front Center | 720 mm | 28.3 inches | 760 mm | 29.9 inches |
12 | BB (Bottom Bracket) Drop | 60 mm | 2.4 inches | 60 mm | 2.4 inches |
13 | Fork Offset | 30 mm | 1.2 inches | 30 mm | 1.2 inches |
14 | Wheelbase | 1230 mm | 48.4 inches | 1280 mm | 50.4 inches |
15 | Total Length | 1980 mm | 78 inches | 2000 mm | 78.7 inches |
16 | Max Seat Height | 950 mm | 37.4 inches | 1010 mm | 39.8 inches |
17 | Min Seat Height | 770 mm | 30.3 inches | 840 mm | 33.1 inches |
18 | Handlebar Height | 1090 mm | 42.9 inches | 1140 mm | 44.9 inches |
19 | Weight (Without Battery) | 31.3 kg | 69 lb | 32.5 kg | 71.7 lb |
